ED-S 115- 230V, Solid.Line drying and heating chambers with natural convection, 118L, 50Hz

Benefits

Important characteristics

Temperature range: +7 °C above ambient temperature to +250 °C
APT.line™ preheating chamber technology
Natural convection
Adjustable exhaust air flap
Controller with timer function
1 chrome-plated rack, incl. shelf supports
Class 2 integrated independent adjustable temperature safety device (DIN 12880) with visual alarm

Designation		EDS115-230V
Option model		Standard
Order number		9090-0020
Performance Data Temperature
Heating-up time to 150 °C [min]		55
Temperature fluctuation at 150 °C [± K]		0.9
Temperature range +7 °C above ambient temperature to [°C]		250
Temperature variation at 150 °C [± K]		2.8
Electrical data
Nominal power [kW]		1.25
Phase (Nominal voltage)		1~
Power frequency [Hz]		50/60
Rated Voltage [V]		230
Unit fuse [A]		6.3
Doors
Unit doors		1
Housing dimensions not incl. fittings and connections
Depth net [in]		24.27
Height net [in]		28.96
Width net [in]		30.1
Internal Dimensions
Depth [in]		15.37
Height [in]		21.67
Width [in]		21.67
Measures
Interior volume [cu.ft.]		4.2
Load per rack [lbs]		44
Net weight of the unit (empty) [lbs]		110
Permitted load [lbs]		165
Wall clearance back [in]		6.3
Wall clearance sidewise [in]		3.94
Environment-specific data
Energy consumption at 150 °C [Wh/h]		300
Fixtures
Number of shelves (std./max.)		1/5
